Design advantages of Pogo pin

First of all, we should pay attention to the production quality before use. The quality of Pogo pin connector is very important. Good quality connector can effectively improve the service life of the product. This is also one of the reasons why the Pogo pin connector is more expensive than the row PIN and row female connector.

The contact place of Pogo pin connector is more convenient and simple than that of row needle and female. The service life of the Pogopin connector is longer than that of the row needle and the row female connector. The contact interface of the row needle and the row female connector needs to be removed and inserted with the correct manipulation to avoid the damage of the row needle and the row female interface. Because when we remove and insert the charger and the docking interface, the hand will tilt more or less at a certain Angle. And the size of the finger strength will also affect the position of the insertion, so that the row of needles, after a long period of friction and lead to the phenomenon of bending needle shape. Pogo pin solves this problem well, as long as it touches the contact interface, the contact method is relatively simple.

Using a cost-effective Pogopin connector can bring us a better practical experience, and it also has a great influence on our daily electronic products, from household appliances to small smart devices (smartwatches, mobile phones, Bluetooth headsets, e-cigarettes, etc.). Cnomax Electronics provides all types of connectivity application solutions, including SATA, POGOPIN, board to board and wire to board. We have many kinds of connector products, which are used for testing, research and development as well as the use of daily products, etc., to meet the needs of our customers.

Pogo pin spring thimble working stroke selection:

Pogo pin spring thimble must be selected according to the space of the product used, choose within the range of work; Too small space will compress the spring of the Pogo pin spring thimble too much, which will affect the service life. Too large space may cause the contact is not in place, impedance is unstable, and the image is instantaneously broken.

Selection of electroplating materials:

Electroplating materials in Pogo pin spring thimble can increase electrical conductivity, prevent oxidation, resist wear, etc. Different materials have different effects. For example, gold has good electrical conductivity. For high-current connectors, products with high impedance requirements generally choose electroplating gold

Electroplating film thickness has those effects:

Pogo pin spring thimble must be contacted when working, it will cause certain friction and wear for a long time. The thickness of the electroplating film will have a great impact on the service life of the product. When used to a certain limit when the electroplating is worn off, there may be too much resistance, impedance instability and so on. The electroplating of the spring antenna thimble of 100,000 times is certainly thicker than that of 10,000 times, so when selecting the product, please be sure to choose the electroplating requirements according to the needs;

The effect of elastic force:

The contact force of the Pogo pin spring thimble originates from the internal spring, and the spring elasticity can directly affect the impedance and stability of the spring antenna thimble. If the elastic force is too large, the friction coefficient will be increased and the service life of the spring antenna thimble will be affected. Cnomax offers all types of pin jack connection application solutions, including connector pin jacks, spring clips, pick up pads and spring pins. Our battery connector products include shrapp, Floating Battery Interconnect system (FBIS) and spring thimble (Pogopin), with a variety of options available to meet the changing needs of smartphones.
